RS-485 to Ethernet Converter – ERS-485
The ERS-485 by Ambetronics is an efficient RS-485 to Ethernet Converter designed for seamless serial data transmission over IP networks. With advanced technology, it offers flexibility and high performance, making it ideal for devices requiring effective communication with RS-485 equipment over an Ethernet network. This economical Modbus-to-Ethernet converter easily integrates with devices featuring RS-485 ports, enabling web connectivity. The ERS-485 eliminates cable length limitations, supporting “serial tunneling” through Ethernet or TCP/IP. It serves as a single-port serial server, converting serial to Ethernet, and excels in cable replacement, virtual COM port connections, simultaneous communication with multiple RS-485 devices, connecting Serial PLCs to Ethernet, and supporting Modbus RTU to Modbus over TCP/IP or Modbus TCP/IP conversion. Key features include LED indication, cost-effectiveness, 10/100Mbps Ethernet speed, TCP/UDP/Telnet modes, DHCP/Static IP modes, web-based configuration, and low power consumption. The converter finds applications in fire and security panels, remote equipment management, access control, industrial control, and home automation. Its technical specifications encompass support for TCP, UDP, DHCP, HTTP, Server-Client, TELNET, and Modbus TCP protocols, 10/100Mbps speed in half-duplex mode, and a built-in HTTP web server for configuration. The compact ABS plastic design with dimensions of 101mm (H) x 58.5mm (W) x 23mm (D) and weighing around 200g allows for easy mounting on Din Rail or walls. The serial interface supports various configurations, including parity bit options, 8 data bits, baud rates from 2400 to 460800 bps, and multiple flow control options. The ERS-485 operates in a temperature range of 0 to 55°C, with a storage temperature range of 0 to 60°C, and relative humidity from 5% to 95% RH (non-condensing).
1. Efficient Connectivity: The ERS-485 converter facilitates seamless communication between devices with RS-485 ports and an Ethernet network, ensuring efficient data transmission.
2. Flexibility and Performance: With advanced RS-485 to Ethernet converter technology, the device offers flexibility and high performance, meeting the demands of various applications.
3. Web-Enabled Devices: Quickly and easily adds web connectivity to any device with an RS-485 serial port, making the device web-enabled for remote monitoring and control.
4. Cable Length Elimination: Converts a serial port to an Ethernet port, eliminating cable length limitations and enabling “serial tunneling” through an Ethernet or TCP/IP network.
5. Versatile Applications: Ideal for diverse applications such as cable replacement, virtual COM port connections, simultaneous communication with multiple RS-485 devices, connecting Serial PLCs to Ethernet, and Modbus RTU to Modbus over TCP/IP or Modbus TCP/IP conversion.
6. LED Indication: Equipped with LED indicators for clear visual status updates, enhancing ease of monitoring and troubleshooting.
7. Cost-Effective Solution: An economical Modbus-to-Ethernet converter providing a cost-effective solution for integrating existing RS-485 devices into Ethernet networks.
8. User-Friendly Configuration: Features web-based configuration, allowing users to easily set up and customize the converter according to their specific requirements.
9. Low Power Consumption: Designed with low power consumption, contributing to energy efficiency and cost savings over time.
Technical Specifications:
1. Protocols Supported:
– TCP, UDP, DHCP, HTTP
– Server-Client, TELNET, Modbus TCP
2. Ethernet Speed: 10/100Mbps in Half Duplex mode
3. Configuration:
– In-built HTTP Web Server for user-friendly configuration.
4. Working Mode: Supports both Server and Client modes.
5. Transmission Distance: Capable of transmission over a distance of 100 meters.
6. Connector: RJ45 for standard Ethernet connectivity.
7. LED Indication: Two LED indicators for status updates.
8. Restart & Factory Reset: Available for easy troubleshooting and device management.
9. Power Supply:
– Power Input: 9V to 24VDC, providing flexibility in power source.
10. Compact Design:
– Compact Size: 101 mm (H) x 58.5mm (W) x 23mm (D)
– Material: ABS Plastic
– Weight: ~200g
– Mounting: Din Rail / Wall mounting for easy installation.
11. Serial Interface:
– Parity Bit: None, Even, Odd
– Data Bit: 8-bit
– Baud Rate: 2400 to 460800 bps
– Flow Control: RTS/CTS or XON/XOFF or No flow control
– Interface Protection: 2KV static protection
– Interface Type: RS-485 (D+, D-, SH)
12. Environmental Conditions:
– Working Temperature: 0 to 55°C
– Storage Temperature: 0 to 60°C
– Relative Humidity: 5% to 95% RH, Non-condensing.
| Fire and Security Panels | Industrial Control |
| Remote Equipment Management | Home Automation |
| Access Control |
