Loop Powered Temperature Transmitter | TMP-215-WP
The TMP-215-WP Loop Powered Temperature Transmitter offers highly reliable and fast sensing technology suitable for various industrial applications. It supports fixed inputs such as RTD, J, K, R, and S types, ensuring versatility in temperature monitoring. With its user-friendly interface and easy installation process, this transmitter provides quick startup and intuitive menu navigation. Featuring a clear display and fast response, it simplifies operation and enhances efficiency. The device supports software calibration with password protection, eliminating the need for trimpots and ensuring security. With industrial standard 4-20 mA output and built-in reverse polarity protection, it ensures accurate and stable performance in demanding environments. The transmitter’s compact weatherproof housing, with IP65 protection rating, offers durability and flexibility in mounting options. Overall, the TMP-215-WP is an ideal solution for temperature monitoring in various industries, offering reliability, accuracy, and ease of use.
1. Loop Powered Temperature Transmitter is Highly Reliable and Fast Sensing Technology.
2. Fixed Input Compatibility: Loop Powered Temperature Transmitter supports RTD, J, K, R, S types.
3. User-Friendly Operation: Simple to Operate and Easy to Install.
4. Power On Startup: Intelligent Electronics for quick startup.
5. Easy-to-Read Display: Ensures clarity and fast response.
6. Password-Protected Programming: Enhanced security with password change facility.
7. Software Calibration: No trimpots required for calibration.
8. Industrial Standard Output: 4-20 mA output for compatibility.
9. Built-In Reverse Polarity Protection: Ensures safety and stability.
10. Reduced Operating Maintenance: Low maintenance costs.
11. Excellent Long-Term Stability: Ensures consistent performance over time.
12. Non-Intrusive Programming (Flameproof Model): Uses Magnetic Pen for programming.
Technical Specifications:
1. Compensation: Automatic Cold Junction Compensation for Thermocouples (J, K, R, S types).
2. Sensor Probe Details: Specify while ordering.
3. Loop Output: Industrial standard 4-20mA with permissible load of 750 ohms at 24VDC, 25mA.
4. Setting: Adjust settings using 3 keys on the front panel or a Magnetic Pen for Flameproof Model.
5. Supply Voltage: 14 to 36 VDC, typically 24VDC, 25mA.
6. Operating Temperature: -40 to 85°C.
7. Humidity: Below 95% non-condensing.
8. Error Monitoring:
– Display: Shows ‘oPEn’ for sensor open/break, ‘Undr’ for under range, ‘ouEr’ for over range.
– Loop Current: Up scale current: 21 mA, Down scale current: 3.7 mA (Scale programmable).
9. General Weatherproof Housing:
– Degree of Protection Class: IP65.
– Housing Material: Polycarbonate, Grey Colour.
– Cable Entry: Thermoplastic Cable Gland (IP-68).
– Dimensions: 120(H) x 100(W) x 55(D) mm.
– Mounting: Wall Mounting or Stand Mounting.
– Weight: Approx. 250 grams.
| Oven, BOD, Incubator, Humidity Chamber | Monitoring Generators, Bearings, Motors, Transformers |
| Foundries for Heat Treatment | Chemical and Hazardous Area Monitoring |
| Iron and Steel Industry | Cement Plants for Process Automation |
| Humidity Chamber | Cement Plants for Process Automation |
| Water Purification and Treatment | Temperature Scanning of Boilers |
| Sugar Industry | Paper and Pulp Industry |
| Chemical and Petrochemical Industries | Water Pumping Stations |
| Power Plants |
